The heavy-duty drive axle described features a double reduction matched pinion and bevel gear with an outboard planetary gear for final reduction. The brake system is foot-operated, hydraulically actuated wet disc brakes with a total braking area of 246 sq. in. Brakes can operate individually or simultaneously, and there's a lever-operated park brake with a disc-type caliper located on the transmission.

Instruments include gauges for water temperature, oil pressure, fuel level, volt meter, and a park brake warning light. The unit also has a back-up alarm. The hydraulic system includes a 30.5 GPM capacity pump at 2200 PSI, a crankshaft-driven gear-type 2-stage pump, a pre-set relief valve, one master cylinder, and one mast side shift cylinder.

The vehicle is equipped with dual headlights, a rear work light, and a combination stop and tail light. The drive tires are 19.5L x 24 with a puncture-proof foam-filled tread, while steer tires vary based on 2WD or 4WD configurations. General dimensions include a wheelbase of 85 inches, an overall length of 153 inches, an overall width of 87 inches, an overall height of 105 inches, ground clearance of 11 inches, and a gradeability of 22%.

Standard features include a driver overhead guard assembly with a rain shield, rear safety mesh screen, walk-thru operator compartment, cushioned adjustable seat with seat belt, safety back-up alarm, safety horn, drive tire fender, deep steps with expanded metal, dual hand entry grips, 2-inch side shift, and puncture-proof drive and steer tires. Optional features include a compressor, air tank, hose reel, 50 ft. hose, deluxe suspension seat with armrests, heater and fan, and four-wheel drive capability.
